Get high-performance cooling, display a favorite animated GIF or static image, monitor real-time PC performance metrics, see music that’s currently playing, stream browser content and more with NZXT CAM software.
2.36” diameter wide-angle LCD display with 640×640 resolution and 60 Hz refresh rate provides a sharp image from any viewing angle
Screen supports the display of custom images, animated GIFs, and CAM system info with adjustable orientation
Powerful Asetek pump provides optimal cooling and up to 2,800 RPM whisper-quiet operation
Includes F140/F120 RGB Core fans
Includes RGB Controller, RGB Fans, & USB Y-Cable
Single breakout cable simplifies installation
Rubber tubing is reinforced with nylon-braided sleeves to prevent leaks
Control custom screen content, RGB, pump speed, and zero-noise fan curves with NZXT CAM software.
CAP
Material
Aluminum, Plastic
Display Orientation
Software adjustable Default, +90, +180, and -90 Degrees
Display Panel Active Area
2.36” (60mm) diameter
Display Color
24-bit true color LCD
Display Resolution
640 x 640 px
Display Brightness
690 cd/m²
Display Panel Type
TFT-LCD (Wide Viewing Angle)
Water Block
Dimensions
Diameter: 81.9mm H: 59.5mm
Material (Block)
Copper
Material (Housing)
Plastic
Pump
Motor Speed
800 – 2,800 ± 300 RPM
Power
12V DC, 0.3A
Radiator
Dimensions
121 x 394 x 27mm
Material
Aluminum
Tube
Length
400mm
Material
Ultra-low Evaporation Rubber with Nylon Braided Sleeve
Fan Specs
Model
F120 RGB Core Fans
Quantity
3
Dimension
120 x 120 x 26mm
Speed
500-1,800 ± 180 RPM
Airflow
78.86 CFM
Air Pressure
2.57 mm H2O
Noise
33.88 dBA
Bearing
Fluid Dynamic Bearing
Power Consumption
12 V DC, 0.2 A, 2.4 W
Fan Connector
4-Pin PWM
Life
60,000 hours / 6 Years
RGB Controller
Dimensions
63.2 x 53.2 x 12.8mm
Weight
52.8g
Mounting
Magnet and 3M Dual Lock
Connection Cables
1x USB 2.0 internal connector 1x SATA power cable
Input Connector
12V DC / 2.6A
RGB Lighting Channels
3
Output Channel Voltage
5V DC
NZXT RGB Channel Output LED Quantity
Up to 40 LEDs per channel and up to 120 LEDs combined total for the total 3 channels
